Wall elevation studio
A clean front drawing you edit directly, with a 3D line view that flies to any wall.
Design · Elevations & cabinet sheets
Shop-ready cabinet drawings from the design you already made.
Edit each wall in a clean elevation studio, then export elevations, a top view and a cabinet schedule with codes and quantities. Every sheet is rebuilt from the plan, so the drawings always match the design.
- Cabinets and appliances
- Codes on everything
- Dimension strings
- Top · Bottom · Side
- Grouped by code and size
- Order list
- Client approval on the schedule
- Sign-off block
How it works
Design the wall, export the package.
- 01
Open the wall elevation studio
Pick a wall or an island side. It opens as a black-line drawing on white, with an optional grid and a 3D line view to orbit.
- 02
Edit in place
Select a cabinet, drag to reorder, resize to standard widths, insert from the catalog strip and set its options in the side panel.
- 03
Export the sheets
Elevations with codes and dimensions, the kitchen top view, a client elevation without dimensions, and the cabinet schedule.
- 04
Send for approval or order
Email the cabinet package to the client to sign, or without a signature, for example straight to the cabinet shop.
Elevations
Drawn with a professional line hierarchy.
Fine outlines, gaps between fronts, the wall in section, appliances drawn in detail and hidden roll-outs dashed. Crown, light rail, toe kick, countertop thickness and backsplash appear as thin profiles.
- Every cabinet and appliance labeled with its code
- Dimension strings above and below, heights at the side
- Center lines for sinks and appliances
- Line colors by part type, in a consistent palette
Top view and schedule
The sheets an installer and a cabinet shop ask for.
The kitchen top view shows every cabinet with its code, several dimension strings per wall, distances to the island and notes. The cabinet schedule lists each unit with its code, size, doors, internal storage and notes, plus an order list grouped by code.
Bathrooms
Bathroom elevations with tile layout and a spec list.
Bathroom walls get their tile zones tagged on the drawing, with a spec list beside it: tile per surface with size, pattern, grout and quantity, and the fixtures with product names, sizes and mounting heights.
What you get
The drawing set, without a drafter.
Cabinet schedule
Codes, sizes, doors, storage and notes, with a grouped order list and run parts.
Kitchen top view
Codes, dimension strings, island distances, waterfall marks and text notes.
Client elevations
Outline elevations without dimensions, for presenting the design.
Bath tile layout
Tile zones per wall with a spec list from the chosen products.
Approval block
A sign-off block on the schedule, ready for Send for signature.
The details
Cabinet parts the drawings understand
- Toe kick under base and tall cabinets
- Crown molding and light rail on uppers
- Fillers and panels, including island end panels
- Continuous countertop with overhang and backsplash
- Islands built from cabinets, with seating overhang and waterfall ends
- Columns, soffits and beams in the elevations
