AI plan reading
Upload an image or a PDF page. Walls, doors and windows come back as editable objects, not a traced picture.
Plan · Floor plans
Start every remodel from a plan you can trust.
Upload the drawing you already have and Modula reads the walls, doors and windows for you, or draw the room in 2D in a few minutes. One plan then drives the 3D model, the renders, the permit sheets and the material quantities.
- Upload the plan you have
- Image or PDF
- Side by side while you draw
- 2D + 3D
- Imperial or metric, any time
- in · ft · cm
- Feeds every later step
- 1 plan
How it works
From a photo of a plan to an editable drawing.
- 01
Upload or draw
Drop in a JPG, PNG or PDF of the existing plan, or start drawing walls on an empty canvas. You choose the space type (kitchen, bathroom, ADU and more) before you start.
- 02
Modula reads it
The AI finds the walls, doors and windows and rebuilds them as real, editable objects at their measured size. Calibrate the scale with one known dimension if the drawing has none.
- 03
Correct and refine
Drag a wall, type a length, add niches, columns, soffits and beams. Dimensions update as you edit, and every change can be undone.
- 04
Carry it forward
Save, and the same plan becomes the 3D model, the render guide, the permit floor plan and the source of every quantity in the material list.
Draw in 2D, check in 3D
A real CAD-style editor that does not need CAD training.
Walls snap and align, openings sit inside their wall, and dimension lines are drawn for you on the outside and inside of the room. Switch between 2D, split and 3D at any moment.
- Walls, doors, windows and wall niches with exact sizes
- Wall thickness, ceiling height and default door size per project
- Room labels and the room's area in square feet
- Undo and redo for every edit to walls and objects
Room structure
Columns, soffits and beams are part of the plan.
Add the structure that is really in the room. Upper cabinets, hoods and tall units are checked against a soffit or beam above them, and objects that run into a column are flagged before anyone orders.
- Soffits and beams with their own height and depth
- Columns placed and sized on the plan
- Warnings when a cabinet runs into a soffit, beam or column
What you get
Everything a remodel plan needs, in one editor.
Exact dimensions
Type a wall length, lock a reference dimension and switch between inches, feet and centimeters.
Live 3D
Every wall you draw appears in 3D at the same moment. Split the screen to see both.
Catalog of real-size objects
Cabinets, appliances, plumbing fixtures, lighting and furniture, each at its real width and depth.
Room structure
Columns, soffits and beams that the design checks and the drawings understand.
Every space type
Kitchens, bathrooms, bedrooms, living rooms, whole-house remodels and ADUs.
The details
What the plan carries into the rest of the project
The plan is not a picture. It is the data every other part of Modula reads, so a change here shows up everywhere else.
- 3D model of the room, generated from the walls and objects
- Structure guide for AI renders, so walls and windows stay where they are
- Permit floor plan, electrical sheet and elevations
- Cabinet schedule with codes and quantities
- Flooring, paint, backsplash and tile quantities
- Room areas for the budget and the material list
AI plan reading gives you a strong first draft. Check the walls against the site before drawings go out.
